Tableau Server SAML Single Sign-On (SSO) with Magento as SAML IdP . Magento SAML IdP extenstion gives you the ability to use your Magento credentials to login into Tableau Server (SP). Here we will go through a step-by-step guide to configure SSO between Tableau Server as SP (Service Provider) and Magento as IDP (Identity Provider).

Pre-requisites: Download and Installation

Installation using Composer:

• Purchase the miniOrange SAML IDP Single Sign-On extension from magento marketplace.
• Go to My profile -> My Purchases
• Please ensure you are using correct access keys (My Profile - Access Keys)
• Paste the access keys in your auth.json file inside your project
• Use the below command to add the extension to your project.

  "composer require {module_name}:{version}"

• You can see the module name and list of versions in the selector below the extension module name.
• Run the following commands on command prompt to enable the extension.

php bin/magento setup:di:compile

php bin/magento setup:upgrade

Manual Installation:

• Download the miniOrange SAML IDP Single Sign-On extension.
• Unzip all contents of the zip inside the MiniOrange/IDPSaml directory.

{Root Directory of Magento} app code MiniOrange IDPSaml

• Run the following commands on command prompt to enable the extension

php bin/magento setup:di:compile

php bin/magento setup:upgrade

Steps to configure Tableau Server SAML Single Sign-on ( SSO ) Login into Magento 2

1. Configure Tableau Server as Service Provider

• Log in to your Tableau Services Manager as Admin Account.
• Navigate to the Configuration tab and select User Identity & Access from left menu bar.
• Click on Authentication Method.

When you are configuring Tableau Server as SAML SP, follow these steps:

• In the miniOrange SAML IDP extension, navigate to the "IDP Metadata" tab to find Metadata URL, or "IDP Entity ID/Issuer," "SAML Login URL," and "Certificate" fields (Optional). You can also Download XML Metadata file to configure Tableau Server as SP and keep it handy.

  In Tableau Step 1:

• Select "SAML" under "Authentication Method".
• Enable SAML authentication for the server by checking the box.

Tableau Server return URL	Enter the URL that Tableau Server users will access.
SAML Entity ID	The entity ID uniquely identifies your Tableau Server installation to the IDP. You can enter your Tableau Server URL again here.
SAML certificate and key files	Click on Select File to upload the SAML x.509 certificate and SAML key. You can generate the self-signed certificate using OpenSSL using the following command openssl req -x509 -sha256 -nodes -newkey rsa:2048 -keyout cert.key -days 365 -out cert.crt

  In Tableau Step 2:

• Click the "Download XML Metadata File" button to download the file. This file is required to set up Magento as an IDP and keep it handy.

  In SAML IDP Extenstion Step 3:

• Navigate to the "IDP Metadata" tab of the Magento SAML IDP module and click the "Download XML Metadata" button.

  In Tableau Step 4:

• Now, click the "Select File" button and upload the "Download XML Metadata" file from the above step 3.

  In Tableau Step 5:

Note: In some cases, you may need to change the assertion values in the Tableau Server configuration to match the assertion names that are passed by your IDP.

• Enter the assertion values that you want to map during SSO.

Username	username
Display name	displayName
Email	email

  In Tableau Step 6:

• You can check or uncheck the checkbox if you wish to enable or disable the SAML Single Logout.

• Click on Save Pending Changes and then click on Pending Changes at the top of the page.

• Click Apply Changes and Restart to restart your Tableau server.

2. Configure Magento as Identity Provider

• In the miniOrage SAML Identity Provider extension, go to Service Provider settings tab of the extension.
• Provide the required settings (i.e. SP Entity ID/Issuer, ACS URL) find to your Service Provider Tableau Server and click on Save button to save your configuration.

3. Attribute Mapping

• In the Magento IDP extension, navigate to the Attribute Mapping tab.
• In the User Attributes section, enter the following information and click on Save .
• You can also add more attributes by clicking on + sign to add attributes.

Name	User Meta Data
username	user_login
displayName	display_name
email	user_email

4. SSO Testing

• Open a new browser or private incognito window and enter your Tableau Server URL, which will redirect you to the Magento login screen.
• Enter your Magento credentials and click the log in button.
• If you are redirected to your Tableau Server start page and successfully logged in, your configuration is correct.
