Joomla OAuth Client Integration with Reddit Single Sign-On (SSO)

Integration of Okta Single Sign-on (Okta SSO) with Joomla using OAuth 2.0 Protocol. The miniOrange Joomla OAuth / OpenID Connect Single Sign-on (SSO) plugin makes it simple to set up Okta SSO into Joomla and enable secure login into Joomla. As a result, users can log in to Joomla and access the site by authenticating with their Okta OAuth Provider credentials.
Visit our Joomla OAuth Client Plugin page to learn more about the features and plans we offer for the Joomla OAuth Single Sign-on (OAuth & OpenID connect) plugin.

Pre-requisites : Download And Installation

Joomla OAuth Client Handbook

This detailed Handbook for the Joomla OAuth/OpenID Single Sign On plugin, gives an in depth explanation of the features of the plugin. You can refer to the handbook at anytime - it is always available to you, either via this link , or directly from the plugin for quicker access.

Setup Okta as OAuth Provider with Joomla OAuth Client

1. Download and Setup Joomla OAuth Client

• Download the zip file for the miniOrange OAuth Client plugin for Joomla from the link here.
• Login into your Joomla site’s administrator console.
• From left toggle menu, click on System, then under Install section click on Extensions.

• Upload the downloaded zip file to install the Joomla OAuth Client plugin.

• Installation of plugin is successful. Now click on Start Using miniOrange OAuth Client plugin.

• Under Configure OAuth tab. Select Okta as an OAuth Provider.

• Now copy the Callback / Redirect URL which is needed while configuring Okta as OAuth Server.

2. Configure Okta as OAuth Provider

• Now go to https://www.okta.com/login and log into your Okta account.
• Go to the Okta Admin panel. Go to Applications -> Applications.

• You will get the following screen. Click on Create App Integration button.

• Select Sign in method as the OIDC - OpenID Connect option and select Application type as Web application, click on Next button.

• You will be redirected to the app details page. Enter App integration name and Sign-in redirect URIs which is copied from Joomla OAuth Client plugin, Or you will get that from miniOrange OAuth/OpenID Connect Client Plugin's 'Configure OAuth' tab under the Redirect/Callback URL field.

• Scroll down and you will see the Assignments section. Select an option for controlled access as Allow everyone in your organization to access, untick the Enable immediate access with Federation Broker Mode and then click on Save button.

• Now you will get the Client ID and Client Secret . Keep these credentials handy for configuring miniOrange OAuth Client Single Sign-On (SSO) plugin.

• From right top header, you will get your domain name. Keep the domain name handy.

Note: Copy the Okta domain to configure Joomla OAuth Single Sign-On (SSO) plugin. eg.( https://dev-32414285-admin.okta.com ) then your domain is dev-32414285.okta.com .

3. Integrating Joomla with Reddit

• Go back to your Joomla Dashboard. Then go to Components.
• Paste the Client ID, Client Secret and Domain. Also Set Client Credentials In header then click on Save Settings. Once Settings are saved then click on Test Configuration.

• Scope & Endpoints are given below, which are required for configuring Joomla as OAuth Client plugin to configure Okta as a custom OAuth or OIDC provider.

Scope:	openid email
Authorize Endpoint:	https://{yourOktaDomain}.com/oauth2/default/v1/authorize
Access Token Endpoint:	https://{yourOktaDomain}.com/oauth2/default/v1/token
Get User Info Endpoint:	https://{yourOktaDomain}.com/oauth2/default/v1/userinfo
Custom redirect URL after logout:[optional]	https://{yourdomain.okta}.com/login/signout?fromURI= <your url>
Set Client Credentials:	In Both (In Header and In Body)

4. Test SSO and Attribute Mapping

• Once you click on Test Configuration button, you will be able to see the attributes in the Test Configuration output as follows.

• Now you have to do Attribute Mapping to perform SSO. Select the attribute name for Email and Username from dropdown. Then click on Save Attribute Mapping button.

• Now you can use Login / SSO URL to perform SSO.

• Now logout and go to your Joomla site's pages where you have added this link. You will see a login link where you placed that button. Click on this button to perform SSO.
• Congratulations, you have successfully configured the miniOrange OAuth Client plugin with your Okta OAuth Provider.
• Click on the Upgrade Plans tab to check out our complete list of features and various licensing plans. OR you can click here to check features and licensing plans.
• If you want to purchase any of the paid version of the plugin, you have to register/login with us in Account Setup tab. OR you can register/login Here .
• In case, you are facing some issue or have any question in mind, you can reach out to us by sending us your query through the Support button in the plugin or by sending us a mail at joomlasupport@xecurify.com.

You have successfully configured Joomla as OAuth Client for achieving Joomla Okta Single Sign-On (SSO) with Joomla for user authentication.

In this guide, you have successfully configured Joomla Okta Single Sign-On (SSO) by configuring Okta as OAuth Provider and Joomla as OAuth Client using our Joomla OAuth Client plugin.This solution ensures that you are ready to roll out secure access to your Joomla site using Okta login credentials within minutes.
