Steps to Configure the ASP.NET OAuth 2.0 Module

Step 1: Download and extract package.

  • Download miniOrange ASP.NET OAuth 2.0 Module.
  • For Setting up the connector, extract the, you will find a DLL file miniorange-oauth-sso.dll, a configuration file oauthsso.config and a file which contain the steps for adding the module into your application.

Step 2: Add the connector in your application.

  • Add miniorange-oauth-sso.dll in bin folder (where your other DLL files exists) for your application.
  • Register miniorangeoauthsso module in your application according to the provided steps in the file.
  • Add the provided configuration file oauthsso.config in the root directory for your application.
  • After integration open browser and browse the connector dashboard with URL below:
  • If it pop up the registration page or login page, you have successfully added the miniOrange oauth sso connector for your application.
  • ASP.NET OAuth Single Sign-On (SSO) - Register
  • Register or Login for configuring the connector.

Step 3: Configure miniOrange ASP.NET OAuth Client

  • Configure your OAuth/JWT Server. While configuring your OAuth/JWT server provide the Redirect/Callback URL from the OAuth/JWT Client.
  • You will get the Client ID, Client Secret, Authorize Endpoint, Access Token Endpoint, Get User Info Endpoint from your OAuth/JWT Server. You need to verify the supported scope with the OAuth/JWT Server.
  • ASP.NET OAuth Single Sign-On (SSO) - ASP.NET OAuth Config
  • Fill all the required details and click on Save Configuration.

Step 4: Test Configuration

  • After saving configuration, click on the Test Configuration button to verify if you have configured correctly.
  • On successful configuration, you will get Attributes Name and Attribute Values on Test Configuration window. The below screenshot shows a successful result.
  • ASP.NET OAuth Single Sign-On (SSO) - Test Configuration

Step 5: Attribute Mapping

  • Map Attribute Names provided by your OAuth/JWT Server with your ASP.NET application Attributes given under Attribute Mapping Section and click on Save Attribute Mapping.
  • ASP.NET OAuth Single Sign-On (SSO) - Attribute Mapping
  • Note: All the mapped attributes will be stored in the session so that you can access them in your application.

Step 6: Integration Code

  • You can find the integration code in Integration Code tab in the connector. Just copy-paste that code snippet wherever you want to access the user attributes.
  • ASP.NET OAuth Single Sign-On (SSO) - Integration Code

Step 7: Add following link in your application for Single Sign-On (SSO)

  • Use the following URL as a link in your application from where you want to perform SSO:
  • For example you can use it as:
    <a href="http://base-url/?ssoaction=login”>Log in</a>"
